Versatile Data Logging Options with the Synergy Nano Controller
• Flexible logging of one or more sensors
• USB export of
logging files for external plotting
• On screen history plot, extendable to
a browser screen
• Webchart feature for plotting to a browser screen that be
manipulated with mouse
• Graphing/plotting directly to PDF or network printer
• Email of alarms, log data, charts, test progress
• FTP transfer of ‘Recipes’
results, configuration files, and backups
• Synergy Manager, Software package
using the Synergy Server to graphically share data
San Diego, California – August 8, 2024 -
TotalTemp Technologies
offers advanced and innovative methods for meeting and optimizing your thermal testing
requirements. We specialize in benchtop thermal testing because small batches are
typically the most cost- effective approach. We offer heat transfer by conduction
with thermal platforms, forced convection as in traditional temperature chambers,
combined systems, and thermal vacuum for Space Simulation.
A new blog post has been added entitled "Product
Testing. Bringing the Receipts," which highlights the data logging
capabilities of TotalTemp's automated controllers. Data acquisition, data
presentation, and data storage are part of the complete environmental test
package available from TotalTemp Technologies.
Product Testing Is All About Verification
Verifying the design, verification
of intended operation in production, verification of compatibility with intended
environments.
Verification of having met thermal testing requirements often involves bringing
receipts in one form or another. The powerful Synergy Nano temperature controller/logger
can easily facilitate proof of having met thermal testing requirements, by a number
of different, convenient methods.
Here is a short list of eight popular ways that the Synergy Nano temperature
controller can make it easier to ‘show the receipts’ of thermal testing work.
 1) Recording and logging of one or more
device temperature sensors. Configurable text log files are an easy, flexible
way to preserve and review test data.
App Note 85
Chainable 16 channel logging module for more sensing points, connects
directly to synergy controller:
App Note 72
 Network version, hooks up via Ethernet:
App Note 162
 2) Export of logging data by USB drive or network connection, to be charted
in Excel or other graphing application.
There are many ways to format the data
and put it into your own custom plot with MS Excel. Here is an outline of some
good methods for plotting in MS Excel:
App Note 60
The Logging to MS Excel demo video.
 3) Controller on screen graph of temperature
profile history which can also be displayed remotely on a networked computer
using the free "WebTouch Remote" browser app.
With the push of a button, you can get a configurable-in-advance, quick
snapshot of the recent history. The below App note shows how to bring this
graphical report or other interactive screens of the Synergy Nano onto a local
web browser:
App Note 134..
 4) Webchart Functionality allows temperature controller to show dynamic
charting from the Synergy controller to log/plot data files in a computer
browser.
This powerful feature allows graphing of test results onto a local web
browser. More detailed, powerful and easily configurable than the graphing from
the controller front panel:
App Note 202.
5) Optional Network Plotting Feature that allows printing results graph
directly to a networked printer. Flexible configurable graphical reporting of
test data to a local network printer or PDF:
App Note 90.
  6) Ability to text or email alarms, result
logs or send to PDF file of graphical data, thus enabling easy cloud storage.
(Item 5, Above Network plotting feature must be enabled to send PDF plots).
Email reporting feature:
App Note 84
Safely store and organize test data online with cloud
storage functionality:
App Note 129.
 7)
Transfer files with FTP capability to communicate testing results from Synergy
controllers to a host PC. Transfer data such as test results, System Profiles or
‘recipes’ and controller backup to locations on local network with this powerful
functionality:
App Note 45.
 8) Synergy Server feature enables
centralized control of testing “Recipes”. Save test results, and configuration
backups for one or several Synergy Nano systems using free Synergy Manager PC
based app. Installs on any Windows PC or server running VMware Player or VMware
ESXi:
App Note 99.
TotalTemp Technologies is here for you. We are happy to help you with the
finer details of making the best use of logging data or other features to meet
your requirements and get the best use of the test equipment.
About TotalTemp Technologies
The primary goal for TotalTemp is to maximize the combined 40 years experience we
have in this highly specialized field and create a new, alternative, "Next Generation"
Thermal Platforms and Temperature Testing equipment. Our Mission is to offer thermal
testing equipment that best suits or customers' requirements. For several decades
there were only two real manufacturers for thermal platforms. It was no secret that
the market demanded a new alternative with better service and lower costs. We heard
you loud and clear and TotalTemp is here to fill that need.
Contact:
TotalTemp Technologies
3630 Hancock Street A
San Diego, CA 92110
Phone: 1-888-712-2228
E-Mail:
Sales@TotalTempTech.com
Web: www.totaltemptech.com
Posted August 12, 2024
|
